Explosion Proof: Is it Really?Case in PointDefinitions
EXPLOSION PROOF: Is it Really?



Simply connecting a sensor to an explosion proof head does not make a temperature assembly explosion proof. To ensure safety,
all components must be properly rated.

I

nstrument engineers are responsible for providing safe and appropriate instrumentation. To declare a system safe, simply because a single component is approved, is dangerous in more ways than one.

“…No chain is
  stronger than its
  weakest link;
  likewise,
  no system is   explosion proof
  if it contains
  non-explosion proof
  components…”

  _
_


Two important factors should be considered whenever a job involves electrical equipment in a hazardous location:

1.

Safety. Is the equipment specified truly safe to use in the proposed environment? If the answer is yes, then on what premise is that answer based?


2.

Liability. If you have determined that the equipment specified is safe, are you prepared to defend that determination in a court room?

No one wants to be responsible for injuring others, especially when easily obtainable safeguards exist. In the event of an unfortunate incident, the consequences can be punitive if the injured party can prove that the designer did not take all reasonable and prudent measures to protect against predicable hazards.

In the event of an accident involving an explosion in a hazardous environment, the attorneys for the injured party will attempt to prove negligence on the designer's part. To do this, they usually will retain some individual or organization recognized as an expert in the field. The designer might be asked what measures were taken to ensure that the equipment was safe. Then, their expert would attempt to point out items missed or not listed under direct examination.

In the United States, Factory Mutual Research Corp. (FMRC) is recognized as one of the experts in the field of industrial safety. For certain installations, many companies, local governments and regulatory agencies require that all electrical equipment must be approved by FM and Underwriters Laboratories (UL). In general, these rules and regulations spell out the location's category by class, division and group. (See Definitions)

When an installation requires that electrical-measuring instruments be placed in locations that are considered hazardous, it is incumbent upon the engineer to see that the installation is safe. The user generally will specify the degree of safety required. For example, a petrochemical company could specify that supplied equipment must be explosion proof for Class I, Division 1, Group B. The user is being very specific as to the level of security expected, referring to Article 500 of the National Electrical Code. Factory Mutual subscribes to this code and references it in their approval guide.

In general, the classification defines the extent of the hazard, taking into account the energy required to ignite certain gas mixtures and the potential forces released as a result. When an assembly is called explosion proof, the sensor assembly manufacturer is certifying to the user that specific steps have been taken to ensure the safety of all Plant personnel.

But, no chain is stronger than its weakest link; likewise, no system is explosion proof if it contains non-explosion proof components. Systems are rendered explosion proof by two means:

_ Design the system so that it cannot release sufficient electrical or thermal energy to ignite the specified gas mixture. Such systems are classified as intrinsically safe.

_ Design the system such that it is capable of containing an internal explosion of a specified flammable vapor air mixture and may contain sufficiently long thread paths such that any escaping gases will be cooled below the ignition temperature of the surrounding atmosphere.
